Sunflower Showerhead: 9 inches.
Handheld showerhead: 5 inches.
Distance from water inlet: 150mm
External thread: G1/2B
Diameter of decorative cover: Φ66mm
Distance from water inlet to fixed bracket: 776
Distance from the water inlet to the highest point: 965-1265
Distance from the water inlet hole to the end surface of the showerhead: 825-1125
Distance from showerhead to water outlet wall: 442
1. Sunflower Showerhead: Single-function sunflower showerhead.
2. Handheld Shower Head: Three-function pressure boosting handheld shower head with silicone cleaner.
3. Main valve core: Φ35 valve core.
4. Water distribution valve: flat-footed ceramic valve core.
5. Shower hose: PVC pipe
6. Move Group: Press the Move Group.
7. Curved and Straight Tubes: Straight tube Φ22 + curved tube Φ19. The curved tube can be adjusted after installation.
8. Underflow outlet: features a 360° rotating underflow outlet function.
